3D IMPORT WITH 3D DXF TECHNOLOGY

Go from "solid to part" seamlessly. Eliminate extra steps. The newest control feature from Hurco is the skills gap buster shops need.

  •  Integrated CAD/CAM and tool path simulation
  • No need to enter feature dimensions – simply click and cut
  • Transform Planes created automatically for easy 5-sided conversational programming – no data entry required
3dimport-1

What is Solid Model Import?

With Solid Model Import you can take a customer's 3D solid model (.stp file) and import it into the control. For 5-sided programming, Solid Model Import is extremely powerful because it automatically creates the transform planes. The Transform Planes are the foundation of how Hurco makes 5-sided programming easy.

For all Hurco CNC machines, the ability to import stp files and select specific features to be machined significantly increases productivity. For example, if you select the floor of a pocket, and then identify the top of the pocket. The pocket depth will automatically be pulled from the model. Then you just pick a tool, verify your speeds and feeds, and you're ready to start making chips.

Benefits:

  • Simplifies programming. Saves time. Preserves accuracy.
  • No need to enter feature dimensions – simply click and cut
  • Transform Planes are created automatically for easy 5-sided conversational programming – no data entry required
3d-import-screen

Basics of DXF and Solid Model Import

Jason Falk goes over the basics of DXF and Solid Model Import.

Drawing and Editing

Jason Falk goes over the basics of drawing and editing within the 3D Import feature.

2D and 3D DXF Walkthrough

Jason Falk walks you through 2D DXF and 3D DXF within the 3D Import feature.

Solid Model Walkthrough

Jason Falk goes over solid models within the 3D Import feature.

Moving Part Zero and Aligning Model

Jason Falk shows you how to move part zero and align model within the 3D Import feature.

Mill Surface Feature

Mike Cope explains the Mill Surface feature in 3D Import, which allows conversational WinMax® users to import solid model .STP files and program 3D toolpaths by selecting desired surfaces.

Adding Multiple Contours Using DXF Import

Mike Cope demonstrates how to quickly bring in multiple contours at once using the DXF import function in Winmax.
